Rusco Spin-Down Filter, 1 Inch (Standard NT100-60)
A reusable 60 mesh screen catches sand, grit and rust flakes in a clear bowl; put a bucket under the red valve and open it to flush in about 2 seconds. 1 to 25 GPM, 1 inch slip PVC ports, no cartridges. It goes last in line, after your treatment tanks.
Watch This Before BuyingMeet Aidan, your water treatment expert
Rusco Spin-Down Filter, 1 Inch (Standard NT100-60)
A reusable 60 mesh screen catches sand, grit and rust flakes in a clear bowl; put a bucket under the red valve and open it to flush in about 2 seconds. 1 to 25 GPM, 1 inch slip PVC ports, no cartridges. It goes last in line, after your treatment tanks.
Watch This Before BuyingMeet Aidan, your water treatment expert
Not sure which filter type fits your sediment?I'm the guy in the videos. Sediment is the easiest well problem to diagnose (lift the toilet tank lid) and the easiest to get wrong on filter choice: a cartridge clogs in weeks on coarse sand, and a spin-down screen passes fine silt straight through. Tell me what you're seeing and I'll tell you exactly what fits: the 10 or 20 inch Big Blue, a Rusco spin-down, the backwashing tank, or the spin-down + cartridge combo that saves the most money on a dirty well.
✓The PVC body (the head), with two 1 inch slip sockets: one in, one out
✓The element: a reusable 60 mesh polyester screen (about 250 microns), with its O-ring
✓The clear cover (the bowl), with its O-ring. Hand tighten only
✓The red purge valve, which threads onto the 1/2 inch nipple on the bottom of the bowl
✓Teflon tape
Not included
✕The PVC fittings that connect it to your pipe: couplings, a 1 x 3/4 inch reducing bushing for 3/4 inch pipe, or slip x FPT bushings for threaded lines
✕Shutoff valves, a bypass, and PVC primer and cement
✕A hose from the purge valve to a drain, if you would rather not use a bucket
1 inch Spin-Down with 60 mesh polyester screen and flush valve (Rusco part 1-60-F)
Flow rate
1 to 25 GPM; needs at least 1 GPM for the spin action
Maximum pressure
150 PSI at 73°F
Maximum temperature
100°F at 40 PSI; for the cold water line
Ports
1 inch slip x slip (PVC solvent weld), in and out
Fits
3/4 or 1 inch plumbing: a reducing bushing on 3/4 inch, slip x FPT bushings for threaded lines
Dimensions
11 3/8 in long with the valve attached, 5 in wide
Body and bowl
PVC body; clear high-impact polymer cover
Screen that ships
60 mesh polyester, 254 microns (.010 inch opening), reusable
Other Rusco screens
Polyester 24, 30, 40, 60, 100, 140, 250, 500 and 1000 mesh (711 to 15 microns), same housing
Flush
Red purge valve on a 1/2 inch nipple at the bottom of the bowl; about 2 seconds at household pressure
Mounting
Vertical, bowl pointing at the floor, held up by the pipe (no bracket)
Certification
IAPMO R&T: certified to NSF/ANSI/CAN 61 (drinking water system components) and listed lead free. Material safety, not contaminant reduction
Warranty
Rusco, 12 months from the original sale; using tools voids it (hand tighten only)
Made in
USA (Rusco)
From Rusco's product page, brochure and installation sheet, and IAPMO R&T's listings for model 1-60-F.
We recommend a plumber
We recommend having a plumber install it; Aidan supports your plumber by phone at 800-460-5810. If you'd rather do it yourself, text Aidan at 443-277-2204 with any questions.
It is the smallest kind of install: an inlet and an outlet, with no drain line and no electricity, so it is about an hour or two of a plumber's time.
What the job involves
Shut off the water and open a faucet to relieve the pressure.
Cut into the line after the pressure tank and after any treatment tanks, so the Rusco is the last thing before the house. Shutoff valves on both sides let you open the bowl later without draining the house.
Glue PVC fittings into the two 1 inch slip sockets. On 3/4 inch pipe, reduce with a 1 x 3/4 bushing; on threaded or CPVC lines, use a slip x FPT bushing or a CPVC fitting. Keep the cement off the clear bowl: Rusco's sheet warns glue will damage it.
On copper pipe, Rusco's sheet shows compression couplings and a ground cable clamped across the filter, so the electrical ground the pipe carries is not broken by the plastic body.
Hang it vertical with the bowl pointing at the floor. The pipe holds it up; there is no bracket. Leave room below for a bucket under the valve and to unscrew the bowl.
Thread the red purge valve onto the bowl's 1/2 inch nipple with the Teflon tape, hand tight. Hand tighten the bowl too: Rusco says using tools voids the warranty.
Let the cement cure as the can directs, turn the water back on slowly, check every joint, and flush once to clear any install debris.
Where it goes
✓Well pump, then the pressure tank
✓The 5 micron Big Blue first after the tank, for fine sediment
✓Then the treatment tanks: softener, acid neutralizer, iron filter
✓The Rusco last, right before the house, to catch media those tanks let past
Rusco's own sheet shows the spin-down between the pressure switch and the pressure tank, where the tank's water flushes it. On a well with treatment tanks we put it last instead: only there does it catch media a tank lets past, the 5 micron Big Blue already keeps sand out of the tanks, and household pressure flushes it just the same.
When to size up: if your pump and plumbing move more than 25 gallons a minute, or your main is 1.5 or 2 inch, the Large 2 inch Rusco ($249, 18 to 100 GPM) is the size. Full sequence with the Big Blue alongside it: our sediment filter install guide.
Flush it when the bowl shows a layer
Look at the clear bowl. When sediment has built up in the bottom, it is time. No calendar, no shutoff.
Put a bucket under the red valve. The flush comes out at full system pressure; a short hose from the valve to a floor drain or sump works better than a bucket.
Open the valve. Household pressure pushes the sediment out in about 2 seconds.
Close it. There is nothing to reset or replace.
Rinse the screen if it looks coated
Shut off the water and relieve the pressure, unscrew the bowl by hand, slide out the polyester screen, rinse it, check both O-rings, and put it back. Hand tight.
Screen turning green or brown?
That is algae, and Rusco says it comes from light reaching the water. It is not harmful, but it clogs the screen. Keep the filter out of direct sunlight; for an outdoor install, Rusco sells a Sun Shield that slips over the clear cover.
Leave the 60 mesh in
The 60 mesh screen stops sand, grit and rust flakes. A finer screen fills faster and still does not reach 5 microns: the finest Rusco makes is 1000 mesh, about 15 microns. Fine sediment is the job of a 5 micron Big Blue after the pressure tank. More: sediment filter micron ratings.
No cartridges to buy. If a screen ever wears out, the 60 mesh replacement is $65. For comparison, a 20 inch Big Blue's 5 micron cartridge is $55 and is changed about every 4 to 6 months. The two do different jobs, and on a well with treatment tanks we recommend both.
"This is a great sediment filter. There is no filtration media to replace, simply open the ball valve to flush out the collected sediment. But be careful, because there is a surprising amount of pressure when you open the valve. It is probably best to run a hose from the valve down to your sump. When you look at the screen, it does not appear to be able to filter fine particles, but since this is a spin-down filter, it creates a vortex that allows the sediment to drop out, removing apparently all of the sediment. We do not find sediment particles on the backs of the screens of our faucets. There are also replacement screens that you can buy, with different mesh sizes, to handle whatever sediment you may be dealing with." ★★★★★
Stephen S., Verified Buyer
Video Guides
Aidan has 32 years of industry experience.
How to Install a Sediment Filter for Well Water (Big Blue & Rusco)
Best Sediment Filter for Well Water (Big Blue, Rusco & Backwashing Compared)
Standard 1" Rusco Spin-Down: Reusable Screen, Clear Bowl, 2-Second Flush
1 to 25 GPM, 150 PSI, 60 mesh (about 250 microns). The backstop at the end of a well line.
Water comes in one side of the head and spins down through the clear bowl, so sand, grit and rust flakes are thrown to the bottom. The 60 mesh polyester screen (about 250 microns) holds anything bigger than its opening, and the clean water leaves the other side. When you see a layer in the bowl, put a bucket under the red valve and open it: household pressure flushes it out in about 2 seconds. No cartridges, no shutoff, no tools.
On a well it goes last in line. The 5 micron Big Blue goes first after the pressure tank and stops fine sediment; your softener, neutralizer or iron filter come next; and the Rusco sits at the end, right before the house, to catch media those tanks let past. It is rated 1 to 25 gallons a minute and fits 3/4 and 1 inch plumbing; if your pump and plumbing move more than 25, or your main is 1.5 or 2 inch, the Large 2 inch is the size.
What it will not do: fine silt, clay, cloudy water and dissolved iron pass a 250 micron screen. Rusco's model 1-60-F is certified by IAPMO R&T to NSF/ANSI/CAN 61 and listed lead free, carries Rusco's 12 month warranty, and is made in the USA. We recommend having a plumber install it: an inlet and an outlet, about an hour or two.
✔1 to 25 GPM
✔1" Slip (PVC)
✔Reusable 60 Mesh Screen
✔Clear Bowl
✔2-Second Flush
✔No Cartridges to Buy
✔Made in USA
Feature
Rusco 1 inch spin-down
20 inch Big Blue kit
Its job on a well
Last in line: catches sand, grit and media a tank lets past
First after the well tank: fine sediment
What it stops
Particles over about 250 microns (60 mesh)
Particles down to 5 microns
Upkeep
Open the red valve over a bucket, about 2 seconds
Shut off the water and change the cartridge, about every 4 to 6 months
Can you see inside?
Yes, clear bowl
No, blue housing
Mounting
Hangs on the pipe, no bracket
Wall bracket and screws (included)
Ports
1 inch slip (glue-in PVC)
1 inch NPT (threaded)
To keep it running
Nothing; a $65 screen if one wears out
$55 per 5 micron cartridge
Price
$145
$195, one 5 micron cartridge in the housing
Its job on a well
Rusco 1 inch spin-downLast in line: catches sand, grit and media a tank lets past
20 inch Big Blue kitFirst after the well tank: fine sediment
What it stops
Rusco 1 inch spin-downParticles over about 250 microns (60 mesh)
20 inch Big Blue kitParticles down to 5 microns
Upkeep
Rusco 1 inch spin-downOpen the red valve over a bucket, about 2 seconds
20 inch Big Blue kitShut off the water and change the cartridge, about every 4 to 6 months
Can you see inside?
Rusco 1 inch spin-downYes, clear bowl
20 inch Big Blue kitNo, blue housing
Mounting
Rusco 1 inch spin-downHangs on the pipe, no bracket
20 inch Big Blue kitWall bracket and screws (included)
Ports
Rusco 1 inch spin-down1 inch slip (glue-in PVC)
20 inch Big Blue kit1 inch NPT (threaded)
To keep it running
Rusco 1 inch spin-downNothing; a $65 screen if one wears out
20 inch Big Blue kit$55 per 5 micron cartridge
Price
Rusco 1 inch spin-down$145
20 inch Big Blue kit$195, one 5 micron cartridge in the housing
✔ Free Tech Support
Buy with us and you have a real water-treatment expert to call whenever you need help. Micron selection, cartridge change intervals, flush schedules, backwash programming, treatment order, whatever comes up, you have my number.
📞 Call Us800-460-5810
✉️ Email Supportsupport@midatlanticwater.net
🕒 Live Hours7 Days/Week, 8AM-5PM EST
Frequently Asked Questions
Size it by flow, not by the size of the house. The Standard 1 inch ($145) is rated 1 to 25 gallons a minute and fits 3/4 and 1 inch plumbing. The Large 2 inch ($249) is rated 18 to 100 gallons a minute and needs at least 18 gallons a minute before the water spins; below that it is a bigger housing, not a better filter. If your pump and plumbing move more than 25 gallons a minute, or your main is 1.5 or 2 inch, get the Large. Otherwise, the Standard. Not sure? Text Aidan a photo of the line coming off your pressure tank at 443-277-2204.
If you have treatment tanks, we recommend both: the two do different jobs. The 5 micron Big Blue goes first after the pressure tank and keeps fine sediment out of the softener, neutralizer or iron filter. The Rusco goes last, after the tanks, and catches media a tank lets past, such as softener resin beads or neutralizer granules, before it reaches your faucets and appliances. To check whether you need sediment filtration at all, lift the lid of the toilet tank you use most and look at the bottom.
Leave the 60 mesh screen it ships with: about 250 microns, a .010 inch opening. It stops sand, grit and rust flakes. Rusco makes polyester screens for the same housing from 24 mesh (711 microns) to 1000 mesh (15 microns), and we stock 140, 500 and 1000 mesh. A finer screen fills faster and still does not reach 5 microns, so fine silt is better handled by a 5 micron Big Blue cartridge after the pressure tank. More: sediment filter micron ratings.
When you see a layer of sediment in the bottom of the clear bowl. How often that is depends on how much sediment your well sends; the bowl tells you, not a calendar. Put a bucket under the red valve, open it, and household pressure flushes it out in about 2 seconds. No shutoff, no tools. The flush comes out hard, so a short hose from the valve to a floor drain or sump works better than a bucket.
That is its job at the end of the line. If a tank's distributor wears out, or a pressure surge or air pocket pushes media out, resin beads or neutralizer and carbon granules can travel into the house. The Rusco sits after the last tank, and its 60 mesh screen holds anything bigger than about 250 microns in the clear bowl, where you can see it. Media in the bowl is a sign to have that tank checked: flush it and text Aidan a photo at 443-277-2204.
It mounts straight up and down with the clear bowl pointing at the floor, because the sediment has to fall to the bottom of the bowl for the spin to work. It cannot go sideways or upside down. The pipe holds it up; there is no bracket. Water enters one side of the head, spins down through the bowl and leaves the other side.
We recommend one. It is an inlet and an outlet, with no drain line and no electricity, so it is about an hour or two of a plumber's time. Aidan supports your plumber by phone at 800-460-5810. If you have done some plumbing and would rather do it yourself, you can; text Aidan at 443-277-2204 with any questions.
Rusco rates the 1 inch for 1 to 25 gallons a minute and publishes a pressure loss curve for each size: the loss rises with flow, and it rises as sediment loads the screen, which is why you flush when the bowl shows a layer. If your pump and plumbing move more than 25 gallons a minute, that is the Large 2 inch, rated 18 to 100.
Rusco warrants its parts to the original purchaser for 12 months from the original sale, and repairs or replaces parts found defective, returned at the customer's expense. Rusco says using tools on it voids the warranty: hand tighten only. New, unopened items can be returned to us within 30 days of delivery with our approval first; a 25% restocking fee applies and you pay the return freight. Full terms: our refund policy.
Customer Reviews
5.0Based on 1 Reviews
5 ★
100%
1
4 ★
0%
0
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Customer Photos
Write a ReviewAsk a Question
Rusco Spin-Down Filter...$145.00
$145, No Cartridges: What a Spin-Down Does and Doesn't Do
A 60 mesh screen you flush in seconds. Here is how it compares with the 20 inch Big Blue, and why we recommend both on a well with treatment tanks.
What a spin-down will not do
The 60 mesh screen opens at about 250 microns (.010 inch). Fine silt, clay and cloudy water pass through it, and so does dissolved iron. There is no 5 micron spin-down screen: the finest Rusco makes is 1000 mesh, about 15 microns. Fine sediment is the job of the 5 micron Big Blue right after the pressure tank.
Two filters, two jobs
20 Inch Big Blue Kit
$195, Then $55 a Cartridge
• Cartridge changed about every 4 to 6 months
• Stops fine sediment down to 5 microns
Goes first, right after the pressure tank
Rusco 1 Inch Spin-Down
$145, No Cartridges
• Flush for about 2 seconds when the bowl shows a layer
• Stops sand, grit and escaped media over about 250 microns
Goes last, after the treatment tanks
They are not rivals. The Big Blue goes first after the pressure tank and stops the fine sediment; the Rusco goes last, after the treatment tanks, and stops the coarse grit and any media a tank lets past. If you have treatment tanks, we recommend both. If you are not sure what your well needs, text Aidan a photo of the bottom of your toilet tank at 443-277-2204.
Why the basic Rusco
In Aidan's words: "We use the Rusco with the mesh inside. It's fairly priced. It's easy to maintain."
The basic version. We sell the Rusco with the polyester screen, not the stainless steel screen or self-backwashing kinds.
Certified materials. Rusco's model 1-60-F is certified by IAPMO R&T to NSF/ANSI/CAN 61, the standard for materials that touch drinking water, and listed as lead free. That covers what the filter is made of; it is not a claim that it removes any contaminant.
Made in the USA by Rusco of Brooksville, Florida, with a 12 month warranty on parts.
Contact Us
800-460-5810
We're here to help.
30-Day Returns + Rusco's 12-Month Warranty
Backed by 32 Years in Water Treatment
The Policy: New, unopened items can be returned within 30 days of delivery, with our approval first. A 25% restocking fee applies and you pay the return freight; opened or installed items cannot be returned. Defects are covered by Rusco's 12 month warranty on parts, and we help you with the claim. Full terms are in our refund policy.
32 YrsEXPERIENCE
10,000+SYSTEMS SOLD
In 32 years in this business, the basic Rusco with the polyester screen is the spin-down we sell. There are no cartridges to buy, and the clear bowl shows you when it needs a flush.
The "Finer Screen" Trap
+
It is tempting to order the finest screen. A finer screen fills faster and still stops well short of 5 microns: the finest Rusco makes is 1000 mesh, about 15 microns. Leave the 60 mesh in the Rusco, and let a 5 micron Big Blue after the pressure tank take out the fine sediment.
How Returns and Warranty Claims Work
1
Arrived Damaged, Missing or Wrong?
Tell us within 3 days of delivery if the item is damaged, missing or wrong. For shipping damage, you file the carrier claim and we help with it.
2
Need to Return It?
Call 800-460-5810 or text Aidan at 443-277-2204 within 30 days of delivery. New, unopened items can be returned with our approval. A 25% restocking fee applies, and you pay the return freight.
Questions After You Buy
Not sure which mesh, which size, or where it goes in the line? Text Aidan a photo of your setup at 443-277-2204 or call 800-460-5810, 7 days a week, 8 AM to 5 PM Eastern.
We use the Rusco with the mesh inside. It's fairly priced and it's easy to maintain: when the bowl fills, put a bucket under it, open the valve, and the household pressure flushes it out in about 2 seconds. Not sure whether you need the Standard or the Large? Text me a photo of your line.
