Well-X-Trol WX-203 32 Gallon Pressure Tank Package with TFP3-RV Tee Kit
Amtrol Well-X-Trol WX-203 | 32 gal | 47 x 15 in | TFP3-RV tank tee kit
Well-X-Trol WX-203 32 Gallon Pressure Tank Package with TFP3-RV Tee Kit
Amtrol Well-X-Trol WX-203 | 32 gal | 47 x 15 in | TFP3-RV tank tee kit
The tank: Amtrol Well-X-Trol WX-203
- ✓32 gallon stand-style well pressure tank, 47 inches tall (including the stand) and 15 inches across
- ✓1 inch NPTF stainless steel system connection on the bottom, where the tank tee threads in
- ✓Heavy-duty butyl diaphragm and antimicrobial liner, so the water does not touch the steel shell
- ✓High-strength steel shell with Amtrol's Tuf-Kote HG Blue finish
- ✓Factory pre-charged by Amtrol to 38 PSI
The tank tee kit: TFP3-RV fitting package
- ✓Double-tapped brass cross that threads onto the tank
- ✓Pressure switch (set at 30/50 or 40/60 PSI; text Aidan before you order to confirm which)
- ✓Pressure gauge, 0 to 100 PSI
- ✓Relief valve
- ✓Stop and waste valve (a shutoff with a drain port)
- ✓Boiler drain and brass nipples
Not included
- ✕The pump, and the pipe, unions or adapters that connect the tee to your house plumbing
- ✕Thread sealant or PTFE tape for assembling the kit
- ✕Wire and electrical parts for the pressure switch
WX-203 specifications
| Model | Amtrol Well-X-Trol WX-203, stand model |
|---|---|
| Tank volume | 32.0 gallons (121 L) |
| Drawdown at 30/50 PSI | 9.9 gallons |
| Drawdown at 40/60 PSI | 8.6 gallons |
| Drawdown at 50/70 PSI | 7.6 gallons |
| Maximum acceptance factor | 0.35 |
| Height | 47 in (1194 mm), including the stand |
| Diameter | 15 in (381 mm) |
| Stand diameter | 12 in (304 mm) |
| System connection | 1 in NPTF, stainless steel |
| Factory pre-charge | 38 PSI |
| Maximum working pressure | 150 PSI |
| Maximum relief valve setting | 125 PSI |
| Shell | High-strength steel |
| Diaphragm | Heavy-duty butyl |
| Liner | Antimicrobial |
| Water circulator | Turbulator |
| Air valve | Projection welded |
| Finish | Tuf-Kote HG Blue |
| Tank shipping weight | 47 lb (21 kg) |
| Tank tee kit | TFP3-RV: double-tapped brass cross, pressure switch, 0 to 100 PSI gauge, relief valve, stop and waste valve, boiler drain, brass nipples |
| Warranty | Amtrol 7-year limited warranty from the date of purchase; read Amtrol's policy on online purchases in the Warranty and Returns tab |
We recommend a plumber
We recommend having a plumber install it; Aidan supports your plumber by phone at 800-460-5810. If you'd rather do it yourself, text Aidan at 443-277-2204 with any questions.
A plumber typically takes 1 to 3 hours to swap a pressure tank in an open basement, about $200 to $500 in labor (our pressure tank cost guide). Crawl spaces, galvanized pipe that needs adapters, or a tank that has to come up stairs push it toward the top of that range.
What the job involves
- ✓Turning off the power to the pump and draining the old tank
- ✓Assembling the tee kit with thread sealant and threading the brass cross onto the tank's stainless connection
- ✓Connecting the line from the well pump and the line to the house
- ✓Wiring the pressure switch to the pump circuit
- ✓Checking the tank's air pre-charge with the tank empty, before the system is filled
Amtrol's own placement rules (installation manual MC10185)
- ✓Mount it vertically only
- ✓Protect it from freezing, and keep it out of direct sunlight
- ✓Do not put it where a leak could damage the floor or the rooms below; where that is a risk, Amtrol calls for a drip pan piped to a drain
- ✓Install the relief valve at the tank's connection to the system piping
- ✓Amtrol says a licensed professional should install it and check the system once a year
How long it lasts
It depends on the tank, how much water you use and how hard the tank works. In Aidan's experience, new tanks have failed within months and others have run 20 years or more. Amtrol's limited warranty is 7 years.
Checks
- ✓Amtrol says a licensed professional should check the whole system, including the tank, once a year
- ✓The air pre-charge is checked only with the tank empty and the system off
- ✓If the tank has lost its air, Amtrol says not to add air or adjust it: a loss of air can mean internal corrosion, and re-pressurizing it could make the tank rupture. That is a call for your plumber
Signs the tank is failing
- ✕Pressure that rises and falls in the shower, or a pump that starts and stops every few seconds
- ✕A dull thud when you knock on the top of the tank: water has pushed into the air chamber and the tank is waterlogged. A waterlogged tank cannot be fixed; it is replaced
Amtrol's 7-year limited warranty
- ✓Seven years from the date of purchase on Well-X-Trol residential well tanks
- ✓For the original purchaser or first user; it cannot be transferred
- ✓Covers defects in material and workmanship at the time of manufacture
- ✓Does not cover labor, shipping, removal or installation costs, property damage, freezing, shipping damage by others, or improper installation or maintenance
- ✓Every claim is approved solely by Amtrol, must be made within 30 days of the failure, and needs proof of purchase, proof of home ownership, and the model and serial number
- ✓A replacement carries the balance of the original warranty
Amtrol's policy on tanks bought online
"Any Well-X-Trol item purchased from an e-commerce source is ineligible for manufacturer support; including, but not limited to: warranty coverage, product registration, shipping damage claims, product returns, technical assistance and promotional awards."
Amtrol, Well-X-Trol Internet Sales Policy (MC10253, 08/26). Read plainly, that includes a tank bought from a website like ours.
Call or text us first with any warranty question. We will tell you whether the claim is handled through Mid Atlantic Water or the manufacturer, where the product must go, and what shipping requirements and charges apply under that product's warranty.
Returns and damage
- ✓New, unopened, uninstalled equipment can be returned within 30 days of delivery. Call for approval first; you pay the return freight; a 25% restocking fee applies, waived when you exchange it for an item of equal or greater value. Opened or installed equipment cannot be returned
- ✓Inspect the delivery when it arrives. If it is damaged, note it on the delivery receipt, take photos, file the claim with the carrier, and tell us within 3 days of delivery so we can help
- ✓Our performance guarantee covers the water treatment systems we size; it does not cover well pressure tanks
Shipping
- ✓Free shipping to the lower 48 states and Washington, DC
- ✓Hawaii: a $500 freight charge, shown at checkout. Alaska: orders cannot be checked out online; call us first
- ✓In-stock orders typically ship in 3 to 5 business days, and we email the tracking
- ✓Depending on weight, orders ship by UPS, FedEx or a freight carrier
What homeowners are saying
Video Guides
Aidan answers the questions well owners ask about pressure tanks.
Well Water Pressure Tank: The Complete Guide (Sizing, PSI, When to Replace)
The Well-X-Trol WX-203 and Its Tank Tee Kit
A 32 gallon Amtrol stand tank, 47 x 15 inches, with the brass tee kit that connects it
The pressure tank holds a cushion of air above a butyl diaphragm. As you run water, that air pushes water out to the house, so the well pump does not start every time a tap opens. The WX-203 holds 32 gallons and delivers 9.9 gallons between pump starts on a 30/50 switch (Amtrol's spec card). Amtrol's sizing table picks it for a pump up to 3/4 HP at about 10 gallons per minute on 30/50, or about 7 on 40/60. In Aidan's words, "the 203 is the tank we recommend for most households."
It ships with the TFP3-RV tank tee kit: the double-tapped brass cross that threads onto the tank's stainless connection, a pressure switch set at 30/50 or 40/60, a 0 to 100 PSI gauge, a relief valve, a stop and waste valve, a boiler drain and brass nipples. The kit ships unassembled. Amtrol pre-charges the tank to 38 PSI.
We recommend having a plumber install it, and Aidan supports your plumber by phone. Amtrol's 7-year limited warranty and its policy on tanks bought online are in the Warranty and Returns tab, in Amtrol's words.
| Feature | This Package | Bought Separately |
|---|---|---|
| Tank | Amtrol Well-X-Trol WX-203 | The same tank |
| Pressure switch, gauge, relief valve | Included (TFP3-RV kit) | TFP3-RV kit, $112.73 |
| Brass cross, shutoff, boiler drain | Included (TFP3-RV kit) | In the same $112.73 kit |
| Shipping to the lower 48 | Free | Not in the $637 parts total |
| Help sizing it before you buy | Aidan, by phone or text | Ask the seller |
| Amtrol's online sales policy | Applies; call or text us first | Applies to any online seller |
✔ Help after you buy
The tee kit ships unassembled with little or no paperwork. Aidan supports your plumber by phone, and answers questions about the pre-charge, the pressure switch and the parts by phone or text.
