Fleck 5600SXT 64,000 Grain Electronic Demand Deluxe Water Softener

64,000 grain capacity with 10% crosslink resin, for 5 or 6 people up to 15 grains, 3 people at 16 to 30, or 4 at 16 to 20

Video thumbnail
Watch This Before Buying Meet Aidan, your water treatment expert
Trusted by 10,000+ Homeowners
Assembled in USA

Fleck 5600SXT 64,000 Grain Electronic Demand Deluxe Water Softener

64,000 grain capacity with 10% crosslink resin, for 5 or 6 people up to 15 grains, 3 people at 16 to 30, or 4 at 16 to 20

Video thumbnail
Watch This Before Buying Meet Aidan, your water treatment expert
Free Shipping to the Lower 48
Arrives ... to
In Stock. Ships from Ohio warehouse by
Aidan
Not sure which softener size you need? I'm the guy in the videos. Text me your water test results and I'll tell you the grain size you need, and whether you need an iron filter or neutralizer ahead of it. If your water is soft enough that you don't need a softener, I'll tell you that too.

Complete 64,000 Grain Water Softener System

  • ✓ Fleck 5600SXT digital control valve: electronic metered (demand) valve with a backlit LCD; settings are saved in memory through a power outage and the clock keeps time for at least 8 hours
  • ✓ Vortech mineral tank: ships empty; holds the 2.0 cu ft of resin
  • ✓ 2.0 cubic feet of 10% crosslink softener resin: in separate bags, loaded at install; a tougher grade than the standard 8%
  • ✓ 1" stainless steel bypass valve: pre-installed on the control valve
  • ✓ Brine (salt) tank with safety float: helps prevent overflow
  • ✓ Fill funnel for loading the resin
  • ✓ Free shipping to the lower 48 states
What ships: the empty mineral tank, the control valve with the bypass valve pre-installed, the brine tank, the softener resin in separate bags, and a fill funnel. Resin is loaded into the tank at install. Drain tubing, pipe fittings and salt are not included. We recommend having a plumber install it; Aidan supports your plumber by phone at 800-460-5810. If you'd rather do it yourself, text Aidan at 443-277-2204 with any questions. For homes with acidic water (pH below 7), add an acid neutralizer before the softener to protect the plumbing.

System Overview

Grain Capacity64,000 grain nominal (supplier rated about 60,000 at full salt, 48,000 at the salt-saving setting)
Resin Volume2.0 cubic feet of 10% crosslink resin
Household Size5 or 6 people up to about 15 grains; 3 people at 16 to 30; 4 people at 16 to 20
Control ValveFleck 5600SXT (electronic demand)
Brine TankIncluded, with safety float (5-year warranty)
Service Flow Rate13 GPM
Connections1" threaded, on the stainless bypass (your plumber supplies the adapters)
Drain1/2" drain tubing (not included)
Salt per RegenerationAbout 10 lb
Water per RegenerationAbout 35 to 65 gallons
Approximate Shipping WeightAbout 150 lb

Vortech Mineral Tank

DesignVortech tank (no gravel bed)
Holds2.0 cu ft of resin
Warranty10-year manufacturer warranty

Fleck 5600SXT Control Valve

RegenerationElectronic demand (meter-initiated)
DisplayBacklit LCD
Power BackupSettings saved in memory; clock keeps time at least 8 hours
ProgrammingTime of day, hardness, capacity, regeneration time, day override (set to 14 days)
Regeneration TimeAbout an hour and a half, 2 AM by default
Bypass1" stainless steel (included, pre-installed)
Warranty5-year Pentair warranty

Contaminants Removed

Hardness (Calcium/Magnesium)Full removal
Iron (dissolved/clear water)Up to about 2 PPM (above that, an iron filter first)
⚡
Bypass pre-installed. Resin ships bagged, loaded at install. We recommend having a plumber install it, typically 2 to 3 hours; the part that takes planning is the 1/2" drain line, with an air gap. Aidan supports your plumber by phone at 800-460-5810. If you'd rather do it yourself, text Aidan at 443-277-2204 with any questions.

Installation Steps (for your plumber)

  1. Shut off the main water supply and relieve pressure at a nearby faucet
  2. Position the softener near a floor drain or utility sink for the drain line (needed for regeneration backwash)
  3. Connect the inlet and outlet to your main water line using 1" connections; water direction is marked on the valve head
  4. Run 1/2" flexible drain tubing from the valve to a floor drain, utility sink or standpipe, within about 20 feet, with an air gap (your plumber sets the routing)
  5. Add a couple of bags of plain pellet softener salt to the brine tank
  6. Open the bypass valve slowly to fill the tank, then switch to service position
  7. Program the 5600SXT valve: time of day, water hardness and capacity (Aidan gives your plumber the numbers)

Recommended System Order

Well / City Supply → Pressure Tank → Sediment Filter → Acid Neutralizer → Water Softener (this unit) → House
Need help? Call 800-460-5810 or text Aidan at 443-277-2204 -- available 7 days a week. Aidan supports your plumber through the install and walks you or your plumber through programming, step by step.
✨
Low maintenance: the 5600SXT handles regeneration automatically. Just keep salt in the brine tank and the system takes care of itself.

Maintenance Schedule

  • Monthly Check salt level. Keep a couple of bags of plain pellet salt in the brine tank, with the salt level always higher than the water level. In Aidan's own 3-person home that is about one 40 lb bag every 30 to 45 days, at about $8 to $10 a bag. Avoid rock salt: it leaves a residue in the tank.
  • When Needed Replace the softener resin. How long it lasts depends on your water: in Aidan's service work, 10% crosslink resin on water protected from iron and chlorine has lasted 30 to 40 years, while iron and chlorine shorten it. Signs: hard water returning, increased salt usage, or resin beads appearing in water. Use the included fill funnel to add fresh resin.
  • Annually Clean the brine tank. Once a year, let the salt run low and clean the tank to remove any salt bridges or mushing that can impair regeneration.
  • As Needed Check the venturi and injector. If regeneration seems sluggish or the system isn't drawing brine, the venturi assembly may need cleaning. Takes 5 minutes with no tools.

Replacement Parts & Media

Pro tip: Always use 10% crosslink resin for replacement: standard 8% breaks down faster, especially if you have any chlorine in your water. Questions about maintenance? Call 800-460-5810 or text Aidan at 443-277-2204.

Video Guides

Watch our water softener guides


Why Choose the Fleck 5600SXT 64,000 Grain Water Softener?

Professional-Grade Hard Water Treatment Backed by 32 Years in the Business

The Fleck 5600SXT 64,000 grain water softener removes the calcium and magnesium behind hard water problems: scale on fixtures, spots on glasses, soap that won't lather and dry skin and hair. Its electronic metered valve counts the gallons you use and regenerates only when the resin needs it, saving salt and water compared to timer-based systems. This system includes 2.0 cubic feet of 10% crosslink softener resin, a tougher grade than the standard 8% resin most softeners use, and better on chlorinated city water. It sits in a Vortech mineral tank. At 64,000 grains, it's sized for 5 or 6 people on water up to about 15 grains per gallon, 3 people at about 16 to 30 grains, or 4 people at about 16 to 20. The Fleck 5600SXT is one of the most widely used residential softener valves, with parts that are easy to find and technicians who know how to service it. The backlit LCD shows remaining soft water capacity, regeneration status, and time of day. Your settings are saved through power outages.
✔ 64,000 Grain Capacity
✔ Fleck 5600SXT Valve
✔ 10% Crosslink Resin
✔ Stainless Bypass Included
✔ Electronic Demand
✔ 5-Year Valve Warranty
Mid Atlantic Water Trust Logos
Feature Our System Others
Control Valve ✔ Fleck 5600SXT (Pentair) Generic / No-Name Valve
Resin Quality ✔ 10% Crosslink (Chlorine-Resistant) Standard 8% or Unknown Grade
Regeneration ✔ Electronic Demand (Water-Use Based) Timer-Based (Wastes Salt & Water)
Bypass Valve ✔ 1" Stainless Steel Included Plastic or Not Included
Power Backup ✔ Settings Saved in Outages Often None: Settings Lost
Warranty ✔ 5-Year Valve + 10-Year Tank 1-Year Limited
Expert Support ✔ 7-Day Phone, Text & Email Limited or None
Salt Tank ✔ Safety Float / Auto Shutoff Basic Tank (Risk of Overflow)
Control Valve
✅ Us Fleck 5600SXT (Pentair)
❌ Them Generic / No-Name Valve
Resin Quality
✅ Us 10% Crosslink (Chlorine-Resistant)
❌ Them Standard 8% or Unknown Grade
Regeneration
✅ Us Electronic Demand (Water-Use Based)
❌ Them Timer-Based (Wastes Salt & Water)
Bypass Valve
✅ Us 1" Stainless Steel Included
❌ Them Plastic or Not Included
Power Backup
✅ Us Settings Saved in Outages
❌ Them Often None: Settings Lost
Warranty
✅ Us 5-Year Valve + 10-Year Tank
❌ Them 1-Year Limited
Expert Support
✅ Us 7-Day Phone, Text & Email
❌ Them Limited or None
Salt Tank
✅ Us Safety Float / Auto Shutoff
❌ Them Basic Tank (Risk of Overflow)
Aidan

✔ Free Tech Support

Buy with us and you have a real water-treatment expert to call whenever you need help: valve settings, sizing for a new home, salt questions, help for your plumber, whatever comes up. You have my number.

📞 Call Us 800-460-5810
✉️ Email Support support@midatlanticwater.net
🕒 Live Hours 7 Days/Week, 8AM-5PM EST

Frequently Asked Questions

The Fleck 5600SXT valve is serviceable: somewhere around 10 to 15 years down the road it may need a piston, seals or a control board, which are common parts and fairly simple to replace. The valve carries a 5-year Pentair warranty and the Vortech mineral tank a 10-year manufacturer warranty. As for the resin: in Aidan's service work, 10% crosslink resin on water protected from iron and chlorine has lasted 30 to 40 years, while iron and chlorine shorten it.

Standard water softener resin uses 8% crosslinking in the polymer structure. Our 10% crosslink resin has a tighter molecular bond that makes it more resistant to chlorine damage, oxidation, and physical breakdown. That matters most on city water with chlorine; iron still shortens any resin's life, which is why high-iron wells get an iron filter first. The higher crosslink percentage also maintains better bead integrity over time, so you get consistent softening performance year after year.

The Fleck 5600SXT tracks your actual water usage and only regenerates when the resin is actually exhausted, not on a fixed timer. This saves salt and water compared to timer-based systems that regenerate whether they need to or not. The valve calculates your remaining soft water capacity based on your programmed hardness level and the amount of water you've used, then triggers regeneration at the optimal time (usually 2 AM). You can also see the remaining capacity on the backlit LCD display.

Size by the number of people and your hardness in grains per gallon, not by bathrooms. On water up to about 15 grains, the 48,000 grain covers 1 to 4 people and is the size most homes buy; 1 or 2 people can run it on water up to about 30 grains. Five or more people, or three or more on water over 15 grains, need the 64,000 or 80,000. The 32,000 grain fits 1 to 3 people up to about 15 grains, but Aidan usually starts homes at the 48,000. Count each 1 ppm of iron as about 5 grains. Not sure? Text Aidan your water test at 443-277-2204 or call 800-460-5810 and he'll tell you the size.

We recommend one. The bypass valve comes pre-installed on the control valve and the resin ships in separate bags, loaded at install, so the plumbing is an inlet and an outlet (1" connections); the part that takes planning is the 1/2" drain line to a floor drain, standpipe or utility sink, with an air gap (drain tubing is not included). A plumber typically completes the install in 2 to 3 hours, and Aidan supports your plumber by phone at 800-460-5810, 7 days a week. Programming the 5600SXT valve is three settings (time of day, hardness and capacity), and Aidan tells you or your plumber the numbers. If you'd rather do it yourself, you can; text Aidan at 443-277-2204 with any questions.

If your water pH is below 7.0 (acidic), yes: you should install an acid neutralizer before the water softener. Acidic water corrodes plumbing over time. The neutralizer raises your pH to a safe level, and the softener then removes the hardness. We sell acid neutralizer and water softener packages that include both systems.

A water softener can take out small amounts of dissolved (clear water) iron along with the hardness, but iron shortens the life of the resin. For higher iron, or orange (oxidized) iron, an iron filter goes in before the softener. Send Aidan your water test before you order: he'll tell you whether the softener alone is enough or you need an iron filter and water softener package.

Customer Reviews
5.0 Based on 2 Reviews
100%
0%
0%
0%
0%
Customer Photos
100reviewers would recommend this product Write a Review Ask a Question
Fleck 5600SXT 64,000 Grain Electronic Demand Deluxe Water Softener
Fleck 5600SXT 64,000 G... $2,195.00

Why Our Water Softener Costs More

Fleck 5600SXT vs Budget Water Softeners

What to Check on Any Water Softener

When comparing water softeners, check whether the valve is metered or timer-based, whether replacement parts are available, the resin grade, the warranty, and who answers technical questions. This system uses a Fleck 5600SXT metered valve you can service with common parts, and 10% crosslink resin.

What to Compare

Budget Water Softener
Lower upfront price
  • Valve: metered or timer? Can you get parts for it?
  • Resin: 8% or 10% crosslink? Who answers your questions?
Ask which valve and resin grade it uses
Our 64,000 Grain System
$2,195
  • Fleck 5600SXT metered valve, serviceable with common parts
  • 10% crosslink resin, plus Aidan's sizing help and support for you and your plumber
5-year valve, 10-year tank warranty

A budget softener costs less upfront. Before you compare prices, compare what is inside: the valve, the resin grade, and who answers when you have a question. This system has a Fleck 5600SXT metered valve you can service with common parts, 10% crosslink resin, and regeneration based on the water you actually use, and Aidan supports you and your plumber by phone at no extra cost.

What You Get With This System

The Fleck 5600SXT is one of the most widely used residential water softener valves: it's proven, parts are easy to find, and technicians know how to work on it. We pair it with 10% crosslink resin, a tougher grade than standard 8% resin that holds up better on chlorinated water.

Every system ships with the bypass valve pre-installed and the resin in separate bags for loading at install, and you get 7-day-a-week expert support from Aidan, who has 32 years in this business. We help you size the system, support your plumber through the install, program the valve, and troubleshoot it, all at no extra cost.
